Patch Notes: 3.3.11

Published in FlexScan3D PatchNotes on February 25th, 2019. Written by Polyga Programmer.

FlexScan3D Patch Notes: 3.3.11

Measurement Tool Updates

Coordinate Tool has been renamed to Measurement Tool.
The updated tool is easier to use and has a wider range of capabilities.

Parameter Dialog	A simple dialog now appears when creating new entities explaining how to generate the measurement and which parameters are required.
Circle/Sphere Measurements	Generate circle/sphere entities and determine its radius, area and circumference.
IGES Export	Export measurement entities to IGES format.

Calibration Tuning Updates

Ballbar Tuning has been renamed to Calibration Tuning

More accurate tuning	In addition to Global Scaling, you can now apply specific tuning directly to your scanner’s calibration.
Tuning with Measurement entities	Scanner accuracy tuning can now be done with a either Ballbar or by using Measurement entities.

New Hotkey Support

FlexScan3D now supports Z axis moving using Shift + Alt + LMB + RMB. Previously, it only supported X-Y axis mesh moving

Reordering scan groups

Scans can now be reordered from within the project window. Drag & Drop a scan to reorder it.

Smooth Merge Improvement

The quality of smooth merge has been improved.

PLY Import

You can now import PLY files into Flexscan3D.

Walkthrough

Compatibility

FlexScan3D 3.3.11 has been tested with the following spinnaker driver and HDI Compact Firmware:

Spinnaker	1.15.0.63
HDI Compact	Firmware v4.7.12.47

We cannot guarantee full functionality with other versions.
